The Neschen HotLam 1650 TH – Engineered in Europe, built for professionals who demand flawless laminating every time.

SKU: 6037411

Call us for more info...
020 7064 9660

Heated Top Roller

Adjustable up to 160°C for superior lamination quality, including hot melt & heat-activated films.

Roll-to-Roll Operation

Streamlined workflow with swing-out shafts and rear control panel for effortless webbing.

Pro-Level Performance

1650 mm working width, 12 m/min speed, and 40 mm electrical nip adjustment for ultimate control.

Specs & Performance Breakdown

Product Overview

Let’s break down what makes the HotLam 1650 TH such a powerhouse in professional lamination:

Feature	Detail
Max Working Width	1650 mm
Max Speed	12 m/min
Top Roller Temp. Range	Up to 160°C
Electrical Nip Adjustment	40 mm for perfect pressure control
Material Handling	Soft substrates, heat-activated & hot melt
Feed Table	Flip-up with adjustable trough
Rear Panel	Yes – for better output & easier webbing
Roll-to-Roll Capable	Yes – includes combination bottom shaft
Safety Features	Foot switch, safety eyes, CE certified

In short: you’re not just buying a laminator – you’re investing in smooth operation, reliable results, and true European craftsmanship.

The Neschen HotLam 1650 TH is where German engineering meets hands-on practicality. Designed in close collaboration with users worldwide, this professional-grade laminator handles media up to 1650 mm wide, offering exceptional flexibility whether you’re working with pressure-sensitive, heat-activated, or hot-melt films.

A heated top roller reaching up to 160°C ensures flawless, bubble-free results even on demanding substrates. With a generous max speed of 12 m/min and precision nip control (electrical adjustment up to 40 mm), this model is built for high-volume output without sacrificing quality.

User-centric features like swing-out supply shafts, a flip-up infeed table, and a rear control panel make setup and webbing intuitive. Whether you're laminating short runs or large print batches, the HotLam 1650 TH delivers reliable results every time.
